exImage.cpp

Convert and save a grayscale image. Load the Vision cover, convert its GPU-resident RGB pixels to Rec.709 grayscale, save the semantic Gray image, and optionally inspect it in Viewer.

ExSDK source-ownedC++Vision

Source

Vision · Vulkan compute

sdk/cpp/examples/vision/image.cpp

Load the Vision cover, convert its GPU-resident RGB pixels to Rec.709 grayscale, save the semantic Gray image, and optionally inspect it in Viewer.

API

Example

1#include <oa/oa.h>
2
3OA_MAIN_PREVIEW("ExampleVisionImage") {
4	auto sourceResult = oa::FnImage::decodeFile(
5		oa::Paths::asset("image/coverVision.jpg"), oa::ImageFormat::Rgb);
6	if (not sourceResult.isOk()) return 1;
7	auto source = oa::move(sourceResult).getValue();
8
9	auto grayscale = oa::FnImage::grayscale(source);
10
11	const oa::Path output = oa::Paths::var("example/vision/coverVisionGrayscale.jpg");
12	if (not oa::Filesystem::createDirectories(output.parentPath()).isOk()) return 1;
13	if (not oa::FnImage::saveFile(output, grayscale, 92U).isOk()) return 1;
14
15	if (not grayscale.validate()) return 1;
16	if (grayscale.width() != 1672 or grayscale.height() != 941) return 1;
17	if (grayscale.format() != oa::ImageFormat::Gray) return 1;
18	if (not oa::Filesystem::isFile(output)) return 1;
19
20	oa::print("Saved grayscale image: {}", output.cStr());
21
22	if (argc > 1 and oa::StringView(argv[1]) == "--preview") {
23		oa::ViewerConfig previewConfig;
24		previewConfig.mode = oa::ViewerMode::Image;
25		previewConfig.title = "OA vision · grayscale cover";
26		previewConfig.width = 1280U;
27		previewConfig.height = 646U;
28		if (not oa::Viewer::preview(engine, oa::Paths::var("example/vision/coverVisionGrayscale.jpg").string(),
29			previewConfig).isOk()) {
30			return 1;
31		}
32	}
33	return 0;
34}
35

Output

Before / after. Compare the checked RGB source with the exact grayscale JPEG written by this example.

OA Vision cover showing a glitched figure in a modern room — source
Vision cover
Download image
The full-resolution RGB source decoded through oa::FnImage.
1672×941 · image/jpegSHA-256 1a0739698875a91967f262254d08c660bf46fe5404a74a8e0d161a4ed72463bfOA-authored Vision module cover

OA Vision cover converted from RGB to grayscale — processed
Grayscale output
Download image
The full-resolution Rec.709 grayscale image converted on the GPU and saved by the source-owned example.
1672×941 · image/jpegSHA-256 163864805a449c278e1abd26b921e502cde9deacfa4dbf5179eef6b44b9b6ed9sdk/py/examples/vision/image.py

Present

The Output section above remains the exact artifact evidence. These captures document the current interactive Viewer surface used by the presentation path.
